ACCELERATE YOUR CREATIVITY
NVIDIA® QUADRO® K2200
Accelerate your creativity with NVIDIA® Quadro®—the world's most powerful workstation graphics.
The NVIDIA Quadro K2200 delivers exceptional power-efficient 3D application performance. 4 GB of GDDR5 GPU memory with fast bandwidth enables you to create large, complex models, and a flexible single-slot form factor makes it compatible with even the most space and power-constrained chassis. Plus, an all-new display engine drives up to four displays with DisplayPort 1.2 support for ultra-high resolutions up to 3840x2160 @ 60 Hz with 30-bit color.
Quadro cards are certified with a broad range of sophisticated professional applications, tested by leading workstation manufacturers, and backed by a global team of support specialists, giving you the peace of mind to focus on doing your best work. Whether you're developing revolutionary products or telling spectacularly vivid visual stories, Quadro gives you the performance to do it brilliantly.
FEATURES
- Two DisplayPort 1.2 Connectors
- DisplayPort with Audio
- DVI-I Dual-Link Connector
- VGA Support1
- NVIDIA nView™ Desktop Management Software Compatibility
- HDCP Support
- NVIDIA Mosaic2
SPECIFICATIONS
| GPU Memory | 4 GB GDDR5 |
| Memory Interface | 128-bit |
| Memory Bandwidth | 80.0 GB/s |
| NVIDIA CUDA Cores | 640 |
| System Interface | PCI Express 2.0 x16 |
| Max Power Consumption | 68 W |
| Thermal Solution | Ultra-Quiet Active Fansink |
| Form Factor | 4.376" H × 7.97" L, Single Slot, Full Height |
| Display Connectors | DVI-I DL + 2x DP 1.2 |
| Max Simultaneous Displays | 3 Direct, 4 DP 1.2 Multi-Stream |
| Max DP 1.2 Resolution | 3840 x 2160 at 60 Hz |
| Max DVI-I DL Resolution | 2560 × 1600 at 60 Hz |
| Max DVI-I SL Resolution | 1920 × 1200 at 60 Hz |
| Max VGA Resolution | 2048 × 1536 at 85 Hz |
| Graphics APIs | Shader Model 5.0, OpenGL 4.53, DirectX 11.24, Vulkan 1.03 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
