01
GPU Core
| Engine | NVIDIA GeForce RTX 5060 Ti |
| CUDA Cores | 4608 |
| AI Performance | 759 TOPs |
| Bus Standard | PCI Express 5.0 |
| OpenGL | OpenGL 4.6 |
| NVLink | Not Supported |
02
Engine Clock
OC Mode
2647MHz
Overclocked
Default Mode
2617MHz
BOOST CLOCK
03
Memory
| Capacity | 16 GB |
| Type | GDDR7 |
| Speed | 28 Gbps |
| Interface | 128-bit |
| Max Resolution | 7680 × 4320 (8K) |
04
Display Outputs
1
HDMI
2.1b Native
3
DisplayPort
2.1b Native
4
Max Displays
Simultaneous
| HDCP | 2.3 Supported |
| Max Resolution | 7680 × 4320 (8K Digital) |
Power Requirements
550
Recommended PSU
Connector
1× 8-pin
Physical
304
Length mm
120
Width mm
50
Height mm
| Slot Width | 2.5 Slot |
In The Box
- 1× Speedsetup Manual
- 1× ASUS Velcro Hook & Loop
- 1× Thank You Card
Software
- ASUS GPU Tweak III
- MuseTree
- GeForce Game Ready Driver
- Studio Driver
* PSU recommendation based on fully overclocked system configuration.
* All specifications subject to change without notice.
* All specifications subject to change without notice.
